Perkins Marine Diesel Engines

Wet Exhaust Elbows: In our selection shown below we offer both original and optional custom built stainless steel exhaust elbows. To ensure you order the correct bolt pattern that will mate to your manifold flange, view the sample manifold images at the bottom of this page.

Custom Built Wet Exhaust Elbows: If you don't see the elbow you need in our selection, you can design your own. The form provided at right makes it easy to orientate and design a stainless steel wet elbow best suited to your application. Just fill out and submit the form for a prompt quote. We assemble these in our own on-site shop to ensure fast delivery times.


Design Your Own Custom Exhaust Elbow

Get full information at the bottom of this page.

     Shown below are numbered photos of some of the most popular water injected exhaust elbows and flanged adaptors. All are stock items at Trans Atlantic Diesels. Please call with the reference number when ordering.

     The exhaust outlet size reflects the inside diameter of the exhaust hose required. Inlet connection is either threaded "National Pipe Thread" male or female or is flanged. Inside diameter of the raw water discharge hose sizes shown with NPT thread sizes where applicable.

PERKINS 100 - 500 SERIES EXHAUST ELBOWS

Reference # M30-01
Request Purchasing Info
Description OEM Part #
M20 / M30 Exhaust Elbow 135616660
2" I.D. Exhaust Hose
1" I.D. Raw Water Hose
Gasket 314990030
Reference # M30-01SS
Description OEM Part #
Stainless Steel Replacement/Option for M20 / M30 Exhaust Elbow 135616660
2" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 314990030
End Cap 24860166
Hose and clamp Kit
(Required to adapt this elbow)
M30SSHCK
  Request Purchasing Info
Reference # M50-60-01
Description OEM Part #
M50 / M60 Exhaust Elbow 4133Y023
2" I.D. Exhaust Hose
1" I.D. Raw Water Hose
Gasket L681VF03
Two Bolt Inlet Flange 3764A092
Gasket for Two Bolt Flange 3683H004
  Request Purchasing Info
Reference # M80-01
Request Purchasing Info
Description OEM Part #
M80 Exhaust Elbow 4133Y031
3" I.D. Exhaust Hose
1" I.D. Raw Water Hose
Gasket L688CF01

PERKINS 4.107 / 4.108 EXHAUST ELBOWS & FLANGES

Reference # 4-108-01
Request Purchasing Info
Description OEM Part #
4.107 / 4.108 Exhaust Flange 37586071
Five Bolt
1" NPT Male
Gasket 12667
Reference # 4-108-02
Request Purchasing Info
Description OEM Part #
4.108 Exhaust Flange 37426472
Four Bolt
2" NPT Female
Gasket 21826388

Stainless Steel replacement option available for flange 4-108-02 above.
Reference 4108-02B - Same four bolt, 2 NPT Female
Request Purchasing Info
Reference # 4-108-03
Description OEM Part #
4.108 Exhaust Elbow PE180 Outlet
Four Bolt
2" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 21826388
  Request Purchasing Info
Reference # 4-108-04
Request Purchasing Info
Description OEM Part #
4.108 Exhaust Elbow Not Available
Four Bolt
2" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 21826388
Reference # 4-108-05
Request Purchasing Info
Description OEM Part #
4.108 Exhaust Elbow 37766713
Four Bolt
2" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 21826388
Two Bolt Flange 37733271
Gasket for Two Bolt Flange 36833154
Reference # 4-108-06
Request Purchasing Info
Description OEM Part #
4.108 Exhaust Elbow E154 LH
2" NPT Male
2" I.D. Exhaust Hose
" NPT Female Inlet
1" I.D. Raw Water Inlet
Also available with Water Inlet on opposite side E154 RH
Reference # 4-108-07
Request Purchasing Info
Description OEM Part #
4.107 / 4.108 Exhaust Elbow 33067
1" NPT Female
2" I.D. Exhaust Hose
" I.D. Water Inlet Hose
" NPT Female Water Inlet
Reference # 4-108-07SS (90)
Request Purchasing Info
Description OEM Part #
4.107 / 4.108 / W40 Stainless Steel Exhaust Elbow
Five Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 12667
Reference # 4-108-07SS (45)
Request Purchasing Info
Description OEM Part #
4.107 / 4.108 Stainless Steel Exhaust Elbow
Five Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 12667
Reference # 4-108-08
Description OEM Part #
4.108 Exhaust Elbow 41316509
Four Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 21826388
Two Bolt Flange Inlet 37733271
Gasket for Two Bolt Flange 36833154
  Request Purchasing Info
Reference # 4-108-09
This part is no longer available, shown for identification purposes only.
Description OEM Part #
4.108 Exhaust Elbow 18200
2" NPT Female
2" I.D. Exhaust Hose
" I.D. Raw Water Inlet Hose
" NPT Female for Inlet

Reference # 4-108-10
Description OEM Part #
4.108 Exhaust Elbow 4133Y001
Four Bolt Flange
OEM # 4133Y001 shown as pattern sample NLA 2" I.D. Exhaust Hose
1" I.D. Water Inlet
Inquire about a custom order
  Request Purchasing Info

Custom Built Stainless Steel Elbow.   Kit as shown below: $795.00
Reference # 4-108-11
Request Purchasing Info
Description OEM Part #
4.107 / 4.108 / W40 Exhaust Elbow 34486
1" NPT Female
2" I.D. Exhaust Hose
" NPT Female
" I.D. Water Inlet Hose
Reference # 4-108-12SS (90)
Request Purchasing Info
Description OEM Part #
4.108 / 4.154 Stainless Steel Exhaust Elbow
Four Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 21826388
Reference # 4-108-12SS (45)
Request Purchasing Info
Description OEM Part #
4.108 / 4.154 Stainless Steel Exhaust Elbow
Four Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 21826388
See #4-108-12SSBOW (45) below for Bowman application. 21826388
Reference # 4-108-12SSBOW (45)
Description OEM Part #
4.108 / 4.154 Stainless Steel Exhaust Elbow for Bowman Manifold
Four Bolt Flange
2" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 21826388
Kit includes items shown above, designed to bolt up to the 4.108 & 4.154 Bowman Manifold.  Kit Price: $695.00
Request Purchasing Info
Reference # 4-108-13BA
Request Purchasing Info
Description OEM Part #
4.108/7 Exhaust Riser / Elbow shown with 45 degree outlet attached to Bowman PE580. Can be configured for either 45 or 90 degree exhaust outlet.
2" I.D. Exhaust Hose
1" I.D. Water Discharge Hose
Bowman Rubber End Cap Part 2486564
Gasket 21826388

PERKINS 4.236 EXHAUST ELBOWS & FLANGES

Reference # 4-236-02
Description OEM Part #
4.236 90 Exhaust Elbow 18450
2" NPT Female
2" I.D. Exhaust Hose
" NPT Female Water Inlet
1" I.D. Water Inlet Hose
  Request Purchasing Info
Reference # 4-236-03
This part is no longer available, shown for identification purposes only.
Description OEM Part #
4.236 45 Exhaust Elbow 18250
2" NPT Female
2" I.D. Exhaust Hose
" NPT Female Water Inlet
1" I.D. Water Inlet Hose
Reference # 4-236-04
Description OEM Part #
4.236 Four Bolt Flange
2" NPT Male
Gasket 36823142
  Request Purchasing Info
Reference # 4-236-05
Request Purchasing Info
Description OEM Part #
4.236 8 Bolt Flange for Bowman Manifold
2" NPT Female
Gasket 36823145
Reference # 4-236-06SS (45)
Reference # 4-236-06SS (90)
Request Purchasing Info
Description OEM Part #
4.236 / 6.354 Stainless Steel Exhaust Elbow
8 Bolt Flange
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 36823145
Reference # 4-236-07SS (45)
Reference # 4-236-07SS (90)
Request Purchasing Info
Description OEM Part #
4.236 / 6.354 Stainless Steel Exhaust Elbow
4 Bolt Flange
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 36823142
Reference # 4-236-08
Description OEM Part #
4.236 / 6.354 Aluminum Exhaust Elbow E236
2" NPT Female
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
  Request Purchasing Info
Reference # 4-236-01
Request Purchasing Info
Description OEM Part #
4.236 Exhaust Elbow PE580 Outlet
Four Bolt Flange
3" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 36823142
Reference # 4-236-01PE580SS
Description OEM Part #
Stainless Steel Wet Exhaust Elbow can be used as shown on Bowman PE580 for 6.354 & PE390 for 4.236
Four Bolt Flange
10 degree Down Angle
3" I.D. Exhaust Hose
1" I.D. Water Inlet Hose
Gasket 36823142
Requires Hose Kit - Reference # PE580SSHK
Bowman 90 degree End Cap - Reference # 2486H903
Request Purchasing Info

PERKINS 6.354 / 6.354.4 EXHAUST ELBOWS

Reference # 6-354-05
Description OEM Part #
6.354 / 4.236 8 Bolt Flange
2 NPT Male
Gasket 36823145
Request Purchasing Info
Reference # 6-354-06SS (45)
Reference # 6-354-06SS (90)
Request Purchasing Info
Description OEM Part #
6.354 / 4.236 Stainless Steel Exhaust Elbow
8 Bolt Flange
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 36823145
Reference # 6-354-07SS (45)
Reference # 6-354-07SS (90)
Request Purchasing Info
Description OEM Part #
6.354 / 4.236 Stainless Steel Exhaust Elbow
4 Bolt Flange
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Gasket 36823142
Reference # 6-3544-08SS (90)
Request Purchasing Info
Description OEM Part #
6.354.4 Nat. Asp. Manicooler Style Adjustable 90 deg elbow Stainless Steel.  Attaches via 4 clamps to original aluminium adaptor (Shown in picture but not included) 37755971
3" I.D. Exhaust Hose
1" I.D. Raw Water Discharge Hose
Gasket 36823141
Reference # 6-354-08
Description OEM Part #
6.354 / 4.236 Aluminum Exhaust Elbow E236
2" NPT Female
3" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
  Request Purchasing Info

PERKINS T6.354 / T6.354.4 EXHAUST ELBOWS & FLANGES

Reference # T6354-01
Request Purchasing Info Elbow currently supplied with heat shield blanket included.

Description OEM Part #
T6.354 Stainless Steel Exhaust Elbow 41316645F
4" I.D. Exhaust Hose
1" I.D. Raw Water Inlet Hose
Clamp 2481942GS
Shim 33415342
Reference # T6354-02
Request Purchasing Info
Description OEM Part #
T6.354 Stainless Steel Can Elbow 37762102F
Clamp between Turbo & T6.354-01 Exhaust Elbow
Clamp 2481942GS
Shim 33415342
Reference # T6354-03H
Request Purchasing Info

Description OEM Part #
Fabricated Stainless Steel turbo mounting adaptor to replace water cooled original unit # 37766601 for HT6.354 which is NLA. Pictured here.
Price of fabricated unit $850.00
Replacement for 37766601
Reference # T6354-04 - Stainless Steel Manifold to Turbo Adaptor
Request Purchasing Info

Description Gaskets Required
Replaces Original Part # 37766681  Constructed of Stainless Steel. Fits between Manifold and Turbo 26740188 (small)
36847152 (large)
Reference # T6-3544-01
Request Purchasing Info
Description OEM Part #
T6.354.4 Stainless Steel Exhaust Elbow 3774K901/A5071
4" I.D. Exhaust Hose
1" Raw Water Inlet Hose
Clamp 2481942GS
Shim 33415342
Reference # T6-3544-02
Request Purchasing Info
Description OEM Part #
T6.354.4 Stainless Steel Exhaust Elbow 37763014F
4" I.D. Exhaust Hose
1" Raw Water Inlet Hose
Clamp 2481942GS
Shim 33415342
Reference # T6-3544-03
Request Purchasing Info
Description OEM Part #
T6.354.4 Stainless Steel Can Elbow 37814702F
4 Bolt Swivel Flange
Clamp to Exhaust Elbows T63544-01 & T63544-02
Gasket 36885003F
Clamp 2481942GS
Shim 33415342
